NIO

NIO ET5 Touring Standard Range

Key Specifications

73.5 kWh Battery
400 km * Range
184 Wh/km * Efficiency

Real Range Estimation

City - Cold Weather *390 km
Highway - Cold Weather *290 km
Combined - Cold Weather *340 km

between 290 - 575 km

City - Mild Weather *575 km
Highway - Mild Weather *375 km
Combined - Mild Weather *460 km

Battery

Nominal Capacity75.0 kWh
Battery TypeLithium-ion
Number of Cells118
Architecture400 V
Warranty PeriodNo Data
Warranty MileageNo Data
Useable Capacity73.5 kWh
Cathode MaterialLFP & NCM
Pack Configuration118s1p
Nominal VoltageNo Data
Form FactorNo Data
Name / ReferenceNo Data

Performance

Acceleration 0 - 100 km/h4.0 sec
Top Speed200 km/h
Electric Range *400 km
Total Power360 kW (489 PS)
Total Torque700 Nm
DriveAWD

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the NIO ET5 Touring Standard Range. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the NIO ET5 Touring Standard Range can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)
Charging PointMax. PowerPowerTimeRate
Wall Plug (2.3 kW)230V / 1x10A2.3 kW37h45m11 km/h
1-phase 16A (3.7 kW)230V / 1x16A3.7 kW23h30m17 km/h
1-phase 32A (7.4 kW)230V / 1x32A7.4 kW11h45m34 km/h
3-phase 16A (11 kW)400V / 3x16A11 kW8 hours50 km/h
3-phase 32A (22 kW)400V / 3x16A11 kW †8 hours50 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the NIO ET5 Touring Standard Range.

  • Max. Power: maximum power provided by charge point
  • Avg. Power: average power provided by charge point over a session from 10% to 80%
  • Time: time needed to charge from 10% to 80%
  • Rate: average charging speed over a session from 10% to 80%
Combined Charging System (CCS Combo 2)
Charging PointMax. PowerAvg. PowerTimeRate
CCS (50 kW DC)50 kW45 kW †72 min230 km/h
CCS (100 kW DC)100 kW80 kW †41 min410 km/h
CCS (150 kW DC)140 kW †110 kW †30 min560 km/h
This vehicle supports Autocharge
This vehicle does not support Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

Dimensions and Weight

Length4790 mm
Width1960 mm
Width with mirrors2178 mm
Height1499 mm
Wheelbase2888 mm
Weight Unladen (EU)2265 kg
Gross Vehicle Weight (GVWR)2730 kg
Max. Payload540 kg
Cargo Volume450 L
Cargo Volume Max1300 L
Cargo Volume Frunk0 L
Roof Load75 kg
Tow Hitch PossibleYes
Towing Weight Unbraked750 kg
Towing Weight Braked1400 kg
Vertical Load Max75 kg

About this Vehicle

# NIO ET5 Touring Standard Range

NIO ET5 Touring Overview

The NIO ET5 Touring represents a compelling entry into the premium electric station wagon segment, combining practical cargo space with impressive performance credentials. This five-door, five-seat estate vehicle targets affluent buyers seeking an alternative to traditional luxury sedans, offering the versatility of a wagon body with cutting-edge electric propulsion. The ET5 Touring distinguishes itself through NIO’s dual-motor architecture, sophisticated battery technology, and a design philosophy that prioritizes both aerodynamic efficiency and interior spaciousness.

The NIO ET5 Touring Standard Range model specifically appeals to European and Asian markets, where station wagons maintain strong appeal. With its 75 kWh battery pack, this configuration balances range requirements with practical daily usability. The vehicle’s 4,790 mm length and 1,960 mm width provide ample interior volume—offering 450 to 1,300 liters of trunk space—while maintaining maneuverability in urban environments. The ET5 Touring matters in the EV landscape as a proof point that electric vehicles can deliver both performance and practicality without compromising on design or technology integration.

NIO ET5 Touring Performance and Driving Experience

The NIO ET5 Touring delivers exhilarating acceleration through its dual-motor all-wheel-drive system, combining a 204 hp induction motor at the front with a 286 hp permanent magnet motor at the rear. This configuration generates a combined 490 horsepower and 700 Nm (516 lb-ft) of torque, propelling the wagon from 0-60 mph in just 3.8 seconds. The low center of gravity inherent to floor-mounted battery architecture, paired with independent multi-link suspension at both ends, creates sharp, engaging handling characteristics that belie the vehicle’s practical wagon proportions.

Real-world driving impressions highlight the NIO ET5 Touring’s refined ride quality, with ventilated disc brakes providing confident stopping power and multiple regenerative braking modes enabling smooth one-pedal driving. The electric power steering and 0.25 drag coefficient contribute to a composed, efficient driving experience suitable for both spirited weekend drives and daily commuting duties.

Specification Value
0-60 mph (0-100 km/h) 3.8 sec (4.0 sec)
Top Speed 124 mph / 200 km/h
Power Output 490 hp / 360 kW
Torque 516 lb-ft / 700 Nm

NIO ET5 Touring Range and Battery Specifications

The NIO ET5 Touring Standard Range features a 75 kWh gross battery capacity with 73.5 kWh usable energy, built on a 400-volt lithium-ion architecture. WLTP testing reveals a range of 445 kilometers (276 miles) for the top trim configuration, though real-world range varies significantly based on driving conditions. Under ideal 90 km/h (56 mph) highway conditions with climate control off, the NIO ET5 Touring achieves approximately 514 kilometers (319 miles). However, with 2 kW heating activated—a realistic winter scenario—range drops to 469 kilometers (291 miles).

Energy efficiency metrics show consumption of approximately 15.7 kWh per 100 kilometers under WLTP conditions, translating to 3.8 miles per kWh. Cold weather and aggressive driving substantially impact these figures, with real-world winter range potentially reaching 290 kilometers (180 miles) in harsh conditions. The battery’s floor-mounted placement optimizes weight distribution and interior space while maintaining structural rigidity.

Range Metric Value
WLTP Range (Top Trim) 445 km / 276 miles
Real-World Range (90 km/h) 514 km / 319 miles
Real-World Range (with Heating) 469 km / 291 miles
Battery Capacity (Usable) 73.5 kWh
Energy Consumption (WLTP) 15.7 kWh/100km / 3.8 mi/kWh

NIO ET5 Touring Charging Times and Options

The NIO ET5 Touring supports both AC and DC charging infrastructure, accommodating diverse charging scenarios from home installations to public networks. Level 2 home charging via a 7 kW wallbox requires approximately 10-11 hours for a complete charge from empty, while 11 kW chargers reduce this to roughly 7 hours. DC fast charging represents the practical solution for longer journeys, though specific peak charging speeds depend on regional infrastructure and battery thermal management systems.

The vehicle’s 400-volt battery architecture enables efficient charging across most European and Asian networks. Practical charging scenarios typically involve overnight Level 2 charging for daily commuting, supplemented by DC fast charging during longer road trips. The inclusion of AC charging capabilities across all 2024+ models enhances flexibility compared to earlier production variants.

Charging Method Time Speed
Level 1 (120V) ~40 hours ~1.8 kW
Level 2 (7 kW) ~10-11 hours 7 kW
Level 2 (11 kW) ~7 hours 11 kW
DC Fast Charge (10-80%) ~30-40 min up to 150 kW

NIO ET5 Touring vs Competitors

The NIO ET5 Touring competes directly with the Tesla Model Y Long Range, BMW iX xDrive50, and Audi Q4 e-tron Quattro in the premium electric wagon/crossover segment. Against the Model Y, the ET5 Touring offers superior cargo versatility through its dedicated wagon design, though the Tesla commands stronger brand recognition and Supercharger network access. Compared to the BMW iX, the NIO ET5 Touring delivers comparable performance with a more efficient powertrain and lower entry price point. The Audi Q4 e-tron presents a closer competitor in terms of size and positioning, though the NIO’s dual-motor architecture provides quicker acceleration and the wagon body offers practical advantages over the Q4’s SUV proportions.

Frequently Asked Questions

Under WLTP testing, the top trim achieves 445 kilometers (276 miles). Real-world range varies from 514 kilometers (319 miles) in ideal highway conditions to approximately 290 kilometers (180 miles) in cold weather with heating activated. Typical daily driving yields 350-400 kilometers depending on climate and driving style.

Home charging via a 7 kW Level 2 charger requires 10-11 hours for a full charge, while an 11 kW charger reduces this to approximately 7 hours. DC fast charging from 10-80% typically takes 30-40 minutes, making it practical for road trips.

The NIO ET5 Touring Standard Range is exclusively all-wheel drive, featuring dual motors with 204 hp at the front and 286 hp at the rear, delivering 490 hp combined output and superior traction across all conditions.

The 75 kWh battery employs a hybrid lithium-ion architecture combining LFP and NCM chemistry on a 400-volt platform, optimizing energy density, thermal management, and longevity while maintaining competitive charging speeds.

The NIO ET5 Touring offers a dedicated wagon body providing superior cargo flexibility, while the Model Y provides stronger brand recognition and extensive Supercharger access. Both deliver comparable 0-60 times around 3.8-4.0 seconds, though the NIO emphasizes practicality over performance positioning.

Yes, the NIO ET5 Touring excels for buyers prioritizing cargo space, performance, and efficiency. Its 490 hp dual-motor system, 445 km WLTP range, and refined driving dynamics make it an excellent choice for European and Asian markets, though availability outside these regions remains limited.> The NIO ET5 Touring Standard Range combines premium electric wagon practicality with impressive performance, delivering 490 horsepower, 445 kilometers of WLTP range, and sophisticated dual-motor all-wheel-drive dynamics in a spacious five-seat estate package. This 75 kWh battery-equipped model represents an intelligent alternative to traditional luxury sedans for buyers seeking versatility without compromising acceleration or efficiency.
